The all-in-one smart home system
Using the built-in temperature sensor, Rithum Switch can operate as a thermostat. Via the Rithum Stat Scheduling screen, users can set a seven day schedule to turn a heating zone on and off with up to eight time points in each day.
Each Rithum Stat triggers a relay via the Philips Hue integration to control the heating zone. Such a Zigbee relay can be wired into a heating zone such as a combi-boiler to turn the heating on and off according to the schedule, or on demand via the Climate screen.
This functionality will be expanded to other integrations in due course.
|Input rating:||100 - 240V~AC 50/60Hz / 12-30VDC|
|Wiring:||Parallel (neutral required)|
|Input current max:||260mA|
|Power consumption standby:||0.7W|
|Wi-Fi:||2.4GHz 802.11bgn (Wi-Fi 4)|
|Environment:||For indoor use only|
|Back box:||Single gang EU 68mm Round or UK 71mm Square|
|Back box depth:||35mm (25mm in some scenarios)|
Generic smart switch topology
Rithum Switch communicates with other systems via your local network, either locally or via the cloud, depending on the integration. It is recommended that a robust network and Wi-Fi system is used to ensure stability. For integration specific topologies see the relevant plugin.
